Concertina Razor Wire – High Security for Commercial, Industrial & Military Use
Razor wire is also known as barbed tape, which is a new type of protective screening with strong protection and isolation ability. It is made of steel plate stamping forming package attached to steel wire. Its sharp blades are chilling. Its blade is fitted with double wire buckle to form a shape of snake abdomen so that it can play a deterrent. What’s more, it has the advantages of good resistance effect and construction expediency.
Description
- Galvanized metal, stainless steel and PVC coated materials for choices.
- Excellent anti-resistance effect.
- Custom sizes available.
- Can be used with various security fencing for higher security grade.
- Available for residential, commercial, industrial and military purpose.
Specification
- Types of Razor wires: BTO-10, BTO-12, BTO-18, BTO-22, BTO-28, BTO-30, CBT-65, CBT-60
- Material of Razor Wire:
- Normal hot dipped galvanized razor wire (40–60 g/m2)
- Heavily zinc coated razor wire (70–270 g/m2)
- Stainless steel 304 or 316 grades razor wire
- Clips of concertina wire: 3 clips, 5 clips or without clips
- Coil Diameter of concertina wire: 300/450/500/600/700/800/950/1000 mm
- Package of razor wires
- Waterproof paper inside, woven bag outside, then 50 rolls/bundle or as required
- Nude package, then packing by wooden pallet or in bulk
| The Coil Diameter | No. of loops | Length Per Coil | Razor Wire Types | Notes |
|---|---|---|---|---|
| 450 mm | 33 | 7–8 m | CBT-60.65 | single coil |
| 500 mm | 56 | 12–13 m | CBT-60.65 | single coil |
| 700 mm | 56 | 13–14 m | CBT-60.65 | single coil |
| 960 mm | 56 | 14–15 m | CBT-60.65 | single coil |
| 450 mm | 56 | 8–9 m(3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 500 mm | 56 | 9–10 m (3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 600 mm | 56 | 10–11 m (3 clips) | BTO-10.12.18.22.28.30 | cross type |
| 600 mm | 56 | 8–10 m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 700 mm | 56 | 8–10 m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 800 mm | 56 | 11–13 m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 900 mm | 56 | 12–14 m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
| 960 mm | 56 | 13–15 m (5 clips) | BTO-10.12.18.22.28.30 | cross type |
| Item | Blade Style | Thickness (mm) | Wire Dia. (mm) | Barb Length (mm) | Barb Width (mm) | Barb spacing (mm) |
|---|---|---|---|---|---|---|
| BTO-12 |  | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 |  | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 |  | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 |  | 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 45±1 |
| BTO-30 |  | 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 45±1 |
| CBT-60 |  | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 |  | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Category
Structure
Flat wrap
Single Coil
Concertina
Material
Galvanized
PVC coated
Stainless steel
